Debut 3.0 DA43 Dolby Atmos® Enabled / On-Wall Speaker
Add height effects to your home theater with the ELAC Debut 3.0 DA43. Place it on top of a bookshelf or floorstanding speaker for up-firing Dolby Atmos playback with a compatible AV receiver, or mount it high on the wall for a direct-firing setup.
Flexible Placement
Use the DA43 on top of your main speakers or mount it high on the wall.
1-Inch Aluminum Dome Tweeter
Reproduces high frequencies with clarity and detail.
4-Inch Aramid Fiber Woofer
Uses a lightweight, rigid cone for controlled sound.
Up-Firing Atmos or On-Wall Placement
For up-firing Dolby Atmos playback, place the DA43 on top of a bookshelf or floorstanding speaker and set the rear switch to Atmos. The speaker directs sound toward the ceiling so it reflects back toward the listening area.
For on-wall use, mount the DA43 high on the wall with the drivers angled toward the listening area and set the rear switch to Wall.
Custom Aluminum Dome Tweeter
The DA43’s 1-inch aluminum dome tweeter combines low weight with high rigidity to reproduce fine high-frequency detail. It brings clarity to the effects and ambience that help create an immersive home theater experience.
Lightweight Aramid-Fiber Woofer
A 4-inch aramid-fiber woofer combines a lightweight cone with the strength needed for controlled movement. Its woven construction supports clear, detailed reproduction in the DA43’s compact enclosure.
Compact Cabinet. Clean Finish.
The DA43 combines an angled, sealed cabinet with a magnetically attached grille. Keep the grille fitted for a discreet appearance, or remove it to reveal the drivers and satin-finished baffle.
| Frequency Response ATMOS: | 73 to 38Khz |
|---|---|
| Frequency Response OnWall: | 73 to 38Khz |
| Nominal impedance | 6 Ω |
| Minimum impedance | 4.4 Ω @ 200Hz |
| Sensitivity @2.83 v/1m | 84 dB |
| Crossover Frequency | 2400 Hz |
| Recommended Ampliifer Power | 20 - 120 W |
| Nominal/Peak Power Handling | 80 W |
| Tweeter | 1 - inch Aluminum dome |
| Midrange (aramid-fiber) | - |
| Woofer (aramid-fiber) | 4.0 “ |
| Cabinet | CARB2 rated 16mm MDF |
| Cabinet Finish | Black Ash vinyl, Satin Black Vinyl Front |
| Enclosure Type | Sealed |
| Binding Post | 5-way metal |
| Width (in / mm) | 6.8/172 |
| Height (in / mm) | 6.7/170 |
| Depth (in / mm) | 9.7/246 |
| Net Weight (lbs / KG) | 7.3/3.3 |
